Description
SPECIFICATIONS
GPU
RX 590, 12 nm FinFET
4th Graphics Core Next (GCN)
Engine Clock
Up to 1560 MHz, Boost
Stream Processors
2304
Memory Size/Bus
8GB GDDR5/256-bit
Memory Clock
8400 MHz effective
Displays
Maximum 5 Outputs
Resolution
DisplayPort: 5120×2880@60Hz
HDMI: 4096×2160@60Hz
DVI:2560×1600@60Hz
Interface
PCI-Express 3.0
Output
- 2x HDMI 2.0b
- 2x DisplayPort 1.4
- 1x DL-DVI-D
BIOS Support
- Dual UEFI
API
- OpenGL® 4.5
- OpenCL 2.0
- DirectX® 12
- Shader Model 5.0
Game Index
1440p gaming
Sapphire Features
- Blue shroud
- NITRO Fan Check
- NITRO Quick Connect System
- NITRO Glow RGB LED
- NITRO CoolTech(NCT)
- Intelligent Fan Control
- Precision Fan Control
- Robust VRM Cooling
- Long Life Polymer Capacitor
- Fuse Protection
- Dual UEFI
AMD Features
- Radeon™ VR Ready Premium
- Radeon™ Software
- Radeon™ FreeSync Technology
- AMD LiquidVR™ Technology
- 4th Gen GCN Architecture
- Radeon™ Chill
- Radeon™ ReLive
- DirectX® 12 Technology
- AMD Eyefinity Technology (Gaming)
- AMD App Acceleration
- AMD CrossFire™ Technology
- AMD CrossFire™ (Bridgeless)
- 3rd Gen 14nm Process Technology
- OpenCL 2.0
- OpenGL 4.5
- AMD PowerTune Technology
- TrueAudio Next
- Unified Video Decoder (UVD)
- Video Code Engine (VCE)
- Virtual Super Resolution
- The Vulkan® API
Cooler Type
- Dual-X fans
- Two ball bearing
Form Factor
- 2.2 Slots Occupied
- 260X135X43 Dimension/mm
Power Consumption
- <235W
OS
- Windows® 11, 10, Windows® 7
- 64bit operating system required
System Requirement
- 500 Watt or greater power supply (Recommended)
- 1 x 8-pin Power Connector + 1 x 6-pin Power Connector
- PCI Express® compliant motherboard with one x16 graphics slot
